Description
SAMSUNG QB49R 49IN 4K UHD USB RJ45 BT LED DISPLAY
4K Mainstream Professional Display for AVSI & Digital Signage Projects with HDMI / DVI / RS232 / USB / RJ45 / Wi-Fi + Bluetooth / Built-in-Speakers /EDGE LED/ HDR+ Functionality/ Tizen 4.0 with Inbuilt Media Player & MagicInfo S6
Features :- Engage customers with lifelike images through ultra high-definition resolution
- Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling technology and unique picture-enhancing features
- Dynamic Crystal Color allows viewers to enjoy a wider spectrum of colors, up to one billion shades
- Engage customers with lifelike images through ultra high-defi nition resolution
- Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling technology and unique picture-enhancing features
- Dynamic Crystal Color allows viewers to enjoy a wider spectrum of colors, up to one billion shades
- New symmetrical, slim design simplifi es installation and complements any environment.
- Secure, PC-free operation through Knox and rigid three-layer protection
SPECIFICATIONS :
Display
Screen Size (Diagonal) |
48.5" |
Resolution |
3840 x 2160 |
Panel Type |
Unspecified LCD |
HDR Compatibility |
HDR10, HDR10+ |
Brightness |
350 cd/m² |
Viewing Angle (H x V) |
178 x 178° |
Aspect Ratio |
16:9 |
Contrast Ratio |
4000:1 |
Response Time |
8 ms |
Backlighting Technology |
Edge LED |
Connectivity
Primary Connectivity Location |
Display |
Input Ports |
2 x HDMI 2.0 – Audio, Video (Side) |
Output Ports |
1 x 1/8" / 3.5 mm – Audio (Rear) |
USB Ports |
1 x USB 2.0 Type-A (Rear) |
Ethernet Ports |
1 (Side) |
Control |
RS-232C via 1/8" / 3.5 mm Input |
Wi-Fi |
Built-in |
Bluetooth |
Yes |
General
TV Tuner |
No |
Display Orientation |
Landscape, Portrait |
HDCP Support |
Yes, Version 2.2 |
Audio
Built-In Speakers |
Yes, 2 x 10 W |
Speaker Configuration |
2-Channel |
Hardware
Operating System |
Tizen 4 |
Processor |
1.7 GHz ARM Coretex A72 Quad-Core |
Storage |
8 GB |
RAM |
2.5 GB LPDDR4 1500 MHz |
Convenience
Supported Video File Types |
H.263, H.264/AVC, H.265/HEVC, MPEG2, MPEG4, VC-1, VP8, VP9 |
Supported Audio File Types |
AC3 |
Supported Photo File Types |
JPEG, PNG |
Electrical
Power Consumption |
Maximum: 138.0 W |
AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
Environmental
Operating Temperature |
32 to 104°F / 0 to 40°C |
Operating Humidity |
10 to 80% |
Certifications |
ENERGY STAR, as per Manufacturer |
Physical
Wall Mounting |
200 x 200mm |
IP Rating |
IP5X |
Bezel Thickness |
9.2 mm (Right/Top/Left) |
Duty Cycle |
16 Hours / 7 Days |
Dimensions |
43.3 x 24.9 x 1.8" / 1099.2 x 631.5 x 46.3 mm |
Weight |
29.76 lb / 13.5 kg |
Packaging Info
Package Weight |
39.15 lb |
Box Dimensions (LxWxH) |
49 x 30 x 6" |
