SAMSUNG OM75D 75IN HIGH BRIGHTNESS LED DISPLAY

Display

Screen Size

75"

Brightness

2,500 nits

Panel Technology

Direct Lit

Contrast Ratio (Typical)

5,000:1

Resolution

1920x1080

Viewing Angle (H/V)

178°/178°

Aspect Ratio

16:9

Response Time

8ms

Connectivity

Input

VGA (D-sub 15 pin), DVI-D, Display Port 1.2
HDMI (2), Component/Composite, Stereo Mini Jack

Output

Display Port 1.2 (Loop-out)
Stereo Mini Jack

External Control

RS232C(In/Out), RJ45

Sensor

Detachable Type (IR, Ambient)

Power

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption (Typical/Max)

550

Power Consumption (Standby)

< 1W

Environmental Conditions

Operating Temperature

32ºF ~ 86ºF

Operating Humidity

10~80%

Features

Special

H/W: Temperature Sensor, Pivot Display, Button Lock, Built in Speakers, Wifi Embedded, Slide-in media player option
S/W: Plug and Play, MagicInfo, Digital Daisy Chains, Lamp Error Detection, Anti Image Retention,, RS232C/RJ45 MDC, PIP/PBP, Video Wall(10x10), Smart Scheduling

24/7 Operation

Yes

SMART Signage Platform

Yes

Media Player Type

Cortex-A9 1GHz Quad Core, 1.5GB DDR3, 8GB FDM, USB 2.0, Linux OS

Vesa Standard Wall-Mount Interface

900 x 600 mm

Built-In Speakers

Built-in Speaker (10W + 10W)

Dimensions

Without Stand (W x H x D)

66" x 37.6" x 4.9"

Packaging (W x H x D)

71.5" x 42.3" x 16.3"

Bezel Width

11.70mm

Weight

Package

132.3 lb.

Service

Standard Warranty

3 Years On-Site (Parts / Labor / Backlight)

Accessories

Optional Media Player

SBB-CF7, SBB-DA, SBB-DI

Green Management

ROHS Compliant

Yes

Packaging Recyclability

Packing Materials Recyclable
